**CS 111 w20 --- Lab 7: The Enigma Machine (pair programming)** *Due: Wednesday, March 04, at 9pm* Your task in this lab is to write a program that simulates the operation of the Enigma machine, which was used by the German military to encrypt messages during World War II. This writeup focuses on what you have to do to complete the assignment. [Additional background](cryptography-background.pdf) on the Enigma machine---and how the codebreakers at Bletchley Park managed to break it---can be found in [cryptography-background.pdf](cryptography-background.pdf). This lab will help you practice - Creating a collection of classes that work together - Handling user interaction events - Using a Python dictionary - Implementing a fairly complex algorithm (the Enigma machine's encryption technique) (##) Logistics To begin, download the starter files in [lab7.zip](lab7.zip) and unzip them to their own folder. These files are - `enigma_main.py`: runs the simulation; you should not need to modify this file - `enigma_constants.py`: defines constants for both the visual appearance and cryptographic algorithm; you should not modify this file - `enigma_machine.py`: the starter file for the `EnigmaMachine` class - `enigma_key.py`: the starter file for the `EnigmaKey` class - `enigma_lamp.py`: the starter file for the `EnigmaLamp` class - `enigma_rotor.py`: the starter file for the `EnigmaRotor` class - `utilities.py`: four useful functions for creating nicely centered `GOval`s, `GRect`s, and `GLabel`s - `pgl.py`: the *Portable Graphics Library* (PGL) file that provides the 2D graphics we're using [^pgl]. You can find nicely formatted, but slightly out date documentation [here](pgldoc/index.html) and messy, but up-to-date documentation [here](pgl.html) - `enigma-top-view.png`: an image of the Enigma Machine as viewed from the top When you run the `enigma_main.py` program as it appears in the starter files, it produces the screen display shown in Figure [initial]. ![Figure [initial]: The output produced by running `enigma_main.py` with the starter files](lab7_images/enigma-top-view.png) Sadly, even though the screen display shows the entire Enigma machine, that doesn't mean that you're finished with the lab. The display is simply a `GImage` that shows what the Enigma machine looks like when viewed from the top. The display produced by the starter program is completely inert. Your job is to make it interactive. You shouldn't need to modify `enigma_main.py`, but it will be useful to read through it to make sure that you understand what it does. You need to make your modifications to the `EnigmaMachine` class and, as you move through the milestones, add the classes `EnigmaKey`, `EnigmaLamp`, and `EnigmaRotor`, each of which is responsible for modeling one component of the machine. Please post your questions on the [Moodle forum](https://moodle.carleton.edu/mod/forum/view.php?id=507509) or bring them to class. --- # Create the Keyboard (Milestone #1) The first step on your way to implementing an interactive Enigma machine is to create the objects for the keyboard. To do this you'll make use of the `EnigmaKey` class defined in `enigma_key.py`. It is a subclass of `pgl`'s `GCompound` class, which means that it contains other graphical objects and that you can add it to the window. **Your task for this milestone is to add code to `EnigmaMachine` to create 26 `EnigmaKey` instances and add them to the `GWindow`.** Since cutting and pasting 26 copies of the same code is both tedious and error prone, you want to perform this operation using a loop that cycles through the letters from A to Z. The index variable of this loop should determine what letter is passed to the `EnigmaKey` constructor. The task of creating the `EnigmaKey` objects is the responsibility of the `EnigmaMachine` constructor (in `enigma_machine.py`. After displaying the background image on the window (which is part of the starter code you were given), you will need to execute a loop that creates each of the 26 keys and then adds it to the `GWindow`. To do so, you need to know where each key belongs on the screen. There isn't any magical way to figure out the location of each key; the only way to figure out where each key goes is to take out a ruler and measure the distance from the upper left corner of the image to the center of each key. But don't panic. That's already been done for you. `enigma_constants.py` includes a constant called `KEY_LOCATIONS` that specifies the *x* and *y* coordinates of the center of each key as a tuple containing the *x* and *y* coordinates. The definition of that constant begins with the lines ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python KEY_LOCATIONS = [ (140, 566), # A (471, 640), # B (319, 639), # C (294, 567), # D (268, 495), # E ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ and ends some lines later with ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python (168, 639), # Y (497, 496) # Z ] ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The value of the `KEY_LOCATIONS` constant is a list with 26 elements corresponding to the 26 letters. The element at index 0 corresponds to the letter A, the element at index 1 corresponds to the letter B, and so on. Each of the elements represents a point on the window. For example, the key for A has its center at the point (140, 566). Note that `enigma_constants.py` also defines a string `ALPHABET` that is the 26 capital letters in order. Those definitions are all you need to get the keys displayed on the screen, and you should definitely get this part working before you move on to the next milestone. Of course, it may not be easy to tell whether your program is working because---at least when you've done everything right---the keys sit exactly on top of the identical image in the background. The only difference is in the font, so make sure your all your keys have gone from this font  to this font  # Make the Keys Respond to Mouse Events (Milestone #2) The version of the program you created at the end of the last milestone does not yet respond to any mouse actions. For this milestone, your job is to implement the `mousedown_action` and `mouseup_action` methods in the `EnigmaKey` class. We want a `"mousedown"` event to change the color of the label on the key to `KEY_DOWN_COLOR`, and a `"mouseup"` event to change the color back to `KEY_UP_COLOR`. This part of the lab is in some ways just as simple as it sounds. Most of the work has already been done in the `enigma_main.py` file. If you look back at the code there, you will see that it defines three event listeners---one for each of the `"mousedown"`, `"mouseup"`, and `"click"` events---and then adds those listeners to the graphics window. The implementation of each of these listeners is almost identical, which means that if you understand one, you will immediately understand the others. The implementation of `mousedown_action` looks like this: ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python def mousedown_action(e): gobj = gw.getElementAt(e.getX(), e.getY()) if gobj is not None: if getattr(gobj, "mousedown_action", None) is not None: gobj.mousedownAction(enigma) ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The `mousedown_action` function begins by using `getElementAt` to find the `GObject` that located at the current mouse position. If there is such an object, the code then uses the built-in `getattr` method to see if that object includes a method called `mousedown_action`. If so, the code in the listener defined in `enigma_main.py` calls that method, passing in the value of `enigma`, which is the `EnigmaMachine` object that keeps track of the state of the Enigma machine. If there is no `mousedown_action` in the object, the event is simply ignored. The advantage of adding these listeners to the main program is that it is now extremely easy to make one of your graphical objects respond to a mouse event. All you need to do is fill in the definition for the `mousedown_action` method. Your task in Milestone #2 is therefore to add `mousedown_action` and `mouseup_action` methods to the `EnigmaKey` class. You'll remove ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python raise NotImplementedError ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ and replace it with code that changes the color of the `GLabel` stored in the instance variable `self.label` (`GLabel` objects have a `setColor` method). Implementing this entire milestone should take exactly two new lines of code. If you find yourself adding more, you're probably on the wrong track. # Create the Lamp Panel (Milestone #3) The area above the Enigma keyboard contains 26 lamps organized in the same pattern as the keyboard. The process of creating the lamps is similar to that of creating the keys. `enigma_constants.py` defines `LAMP_LOCATIONS` the same way as `KEY_LOCATIONS`. Copy the code you wrote in the `EnigmaMachine` constructor and modify it to add `EnigmaLamp`s at the appropriate locations. You should see the font for all the lamps change from this  to this  One important difference from creating the keys is that you should save information about which `EnigmaLamp` object goes with which letter because you will need it for Milestone #4. A good way to do this is create an instance variable in the `EnigmaMachine` constructor that stores a dictionary mapping letters to `EnigmaLamp`s. You can initialize the empty dictionary like this ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python self.lamps = {} ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Each time you create a lamp and add it to the graphics window, also store an entry in the dictionary with the letter as the key and the `EnigmaLamp` object as the value. You can check if this worked by printing out `self.lamps` after you've added everything. You should see something like this (entries for `'C'` through `'Y'` omitted for space; your output won't have each entry on its own line): ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python {'A': < enigma_lamp.EnigmaLamp object at 0x00000251825BEFD0 >, 'B': < enigma_lamp.EnigmaLamp object at 0x00000251825C2208 >, ... 'Z': < enigma_lamp.EnigmaLamp object at 0x00000251825CAC88 >} ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ # Connect the Keyboard and Lamp Panel (Milestone #4) Unlike the keyboard, the lamp panel does not respond to mouse events that occur when you press or click the mouse on one of the lamps. Eventually, you want pressing one of the keys to light the lamp corresponding to the encrypted version of that character after the signal passes through all the encryption rotors. Before you get to that, however, it makes sense to see whether you can extend your program so that pressing one of the keys---in addition to changing the key color---also lights the corresponding lamp. Thus, if you press the A key, for example, you would like the label on the A lamp to appear to glow by changing the text color to the yellowish shade defined by the constant `LAMP_ON_COLOR`. Once again, this task may initially seem simple. For Milestone #2, you implemented the `mousedown_action` for keys so that it changes the key color. Changing the lamp color, however, is slightly more difficult. For keys, the `mousedown_action` method is defined within the code that creates the key and therefore has access to the label as an instance variable of the object. The code that creates each individual key, however, doesn't know anything about the lamps. Moreover, if you use good object-oriented design, the keys shouldn't know anything about the lamps. Working with lamps is the responsibility of the `EnigmaMachine` class. The best way to maintain the a clean design is to have the `mousedown_action` and `mouseup_action` methods pass along the fact that the user pressed or released a key on the keyboard to the `EnigmaMachine` object by calling a method on the `enigma` parameter. If, for example, the `EnigmaMachine` class defines `key_pressed` and `key_released` methods, `mousedown_action` and `mouseup_action` in `EnigmaKey` can call these methods and leave the implementation to the `EnigmaMachine` class, which is where it belongs. The code for those two `EnigmaMachine` methods can then call `turn_on` or `turn_off` on the appropriate `EnigmaLamp` object to achieve the desired effect. The dictionary you created in Milestone #3 will come in handy here, as it will allow you to get the `EnigmaLamp` object that corresponds to the `letter` parameter. Speaking of `turn_on` and `turn_off`, now is the time to implement them. Fortunately, all they need to do is set the color of the label to `LAMP_ON_COLOR` and `LAMP_OFF_COLOR`, respectively. # Add the Rotors (Milestone #5) The encryption rotors for the machine are positioned underneath the top of the Enigma panel. The only part of a rotor you can see is the single letter that appears in the window at the top of the Enigma image. For example, in the diagram shown in Figure [initial], you see the letters  at the top of the window. The letters visible through the windows are printed along the side of the rotor and mounted underneath the panel so that only one letter is visible at a time for each rotor. Whenever a rotor turns one notch, the next letter in the alphabet appears in the window. The act of moving a rotor into its next position is called ***advancing*** the rotor and is discussed in more detail in the description of Milestone #6. For this milestone, your job is to add code the to `EnigmaMachine` constructor to add the rotors to the display. As with the keys and lamps, rotors have a visible component, `EnigmaRotor`, implemented as a `GCompound` subclass. In this case, the `GCompound` includes a small `GRect` colored to match the piece of the rotor visible through the window and a `GLabel` that shows the letter. As in the earlier structures, a constant called `ROTOR_LOCATIONS` gives the x and y coordinates of the three rotors, numbering them from left to right. As noted in the [Background Handout](cryptography-background.pdf), the rotor on the left is called the ***slow rotor***, the one in the middle is the ***medium rotor***, and the one on the right is the ***fast rotor***. Also like the previous milestones, you can tell the rotors have been added correctly when the font changes. One aspect of the `EnigmaRotor` class that makes it different from `EnigmaKey` and `EnigmaLamp` is that in addition to the visible component that appears in the display window, each of the rotors defines a letter-substitution cipher by specifying a permutation of the alphabet in the form of a 26-character string. The permutations for each of the three rotors---which in fact correspond to rotors in the real Enigma---are supplied in the `enigma_constants.py` file in the form of the following list: ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python ROTOR_PERMUTATIONS = [ "EKMFLGDQVZNTOWYHXUSPAIBRCJ", # Permutation for slow rotor "AJDKSIRUXBLHWTMCQGZNPYFVOE", # Permutation for medium rotor "BDFHJLCPRTXVZNYEIWGAKMUSQO" # Permutation for fast rotor ] ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The permutation for the slow rotor, for example, is `"EKMFLGDQVZNTOWYHXUSPAIBRCJ"`, which corresponds to the following character mapping:  At the moment, you don't have to implement the permutation; you will have a chance to do that in Milestone #7. All you need to know is that `EnigmaRotor` constructor takes the permutation for the rotor as an argument and stores it as an instance variable. For example, if you're creating the slow rotor, you have to pass in the string `"EKMFLGDQVZNTOWYHXUSPAIBRCJ"` to the `EnigmaRotor` constructor. You will need to reference the rotor's `permutation` and `offset` instance variables in the `EnigmaMachine`'s `encrypt` method, so you should store a list of the `EnigmaRotor` objects in an instance variable when you create them. # Implementing Advancing for the Rotors (Milestone #6) When the German Enigma operator wanted to send a message, the first step in the process was to set the position of the rotors to a particular three-letter setting for that day. The settings for each day were recorded in a codebook, which the British were never able to obtain. For example, if the codebook indicated that the setting of the day were JLY, the operator would manually reposition the rotors so that they looked like this:  In the Enigma simulator, you enter the day setting by clicking on the rotors. Each mouse click advances the rotor by one position. To enter the setting JLY , for example, you would click 9 times on the slow rotor, 11 times on the medium rotor, and 24 times on the fast rotor. Implementing the click operation to advance the rotor requires just a few changes. A `click_action` method has already been implemented for the `EnigmaRotor` class, which will be called when the click occurs. The body of the `click_action` method is a single line that calls the `advance` method to advance the rotor on which the click occurred. Your task is to fill in the definition of the `advance` method. This method should do two things: 1. Increment the rotor's `offset` 2. Changes the displayed letter to correspond to the new offset The `offset` represents the number of positions the rotor has advanced. When the offset is 0 (as it is for all rotors in Milestone #5), the letter in the display is A. When the rotor advances one position, the offset changes to 1 and the letter in the display changes to B. Advancing a rotor is just rotating a circle, so it will eventually come back around to the start. If the offset is 25, which means that the display shows the letter Z, advancing the rotor changes the offset back to 0 and displays the letter A. You should use the `setLabel` method to change the text displayed by the rotor's `label` instance variable. # Implement One Stage in the Encryption (Milestone #7) So far in this assignment, you've implemented lots of graphics and worked on the underlying classes, but haven't as yet done any encryption. Since Milestone #4, your program has responded to pressing the letter Q by lighting the lamp for the letter Q . Had the Germans used a machine that simple, the codebreakers could have all gone home. The Enigma machine encrypts a letter by passing it through the rotors, each of which implements a [simple letter-substitution cipher](http://practicalcryptography.com/ciphers/simple-substitution-cipher/). Instead of trying to get the entire encryption path working at once, it makes much more sense to trace the current through just one step of the Enigma encryption. For example, suppose that the rotor setting is AAA and the Enigma operator presses the letter Q . Current flows from right to left across the fast rotor, as shown in Figure [onestage]. ![Figure [onestage]: First step on the encryption path when the operator presses Q](lab7_images/one-stage.png) The wiring inside the fast rotor maps that current to the letter I, which you can determine immediately from the permutation for the fast rotor, which looks like this:  So far, so good. The process of translating a letter, however, is not quite so simple because the rotor may not be in its initial position. What happens if the offset is not 0? If the offset of the fast rotor were 1 instead of 0, the encryption would use the wiring for the next letter in the alphabet. Thus, instead of using the straightforward translation of Q to I , the program would need somehow to apply the transformation implied by the next position in the permutation, which shows that R translates to W. Focusing on the letters, however, is likely to get you confused. The problem is that the positions of the letters on each end of the rotor chain are fixed. After all, the lamps and keys don't move. What happens instead is that the rotor connections move underneath the letters. It is therefore more accurate to view the transformation implemented by the fast rotor in the following form:  When the rotor advances, the letters maintain their positions, but every wire rotates one position to the left with respect to the top and bottom connections. After advancing one notch, the rotor looks like this:  The change in the wiring is easiest to see in the straight line that connects N to N in the original state. After advancing, this wire connects M to M. If you press the Q key again in this new configuration, it shows up on the other side of the rotor as V:  What's happening in this example is that the translation after advancing the rotor is using the wire that connects R to W in the initial rotor position. After advancing, that wire connects Q and V, each of which appears one letter earlier in the alphabet. If the rotor has advanced *k* times, the translation will use the wire *k* steps ahead of the letter you're translating. Similarly, the letter in that position of the permutation string shows the letter *k* steps ahead of the letter you want. You therefore have to add the offset of the rotor to the index of the letter before calculating the permutation and, after doing so, subtract the offset from the index of the character you get. In each case, you need to remember that the process of addition and subtraction may wrap around the end of the alphabet. You therefore need to account for this possibility in the code. The modulo operator will come in very handy here. The strategy expressed in the preceding paragraph can be translated into the following pseudocode method, which you should implement in the `apply_permutation` function in the `enigma_rotor.py` module: ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python def apply_permutation(letter, permutation, offset): # compute the alphabetic index of the letter and add the offset to it, wrapping around if necessary # look up the character at that index in the permutation string # compute the alphabetic index of the character from the permutation string # return the character corresponding to this index after subtracting the offset, wrapping if necessary ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Note that you can use `ALPHABET.index(letter)` to get the index of `letter` within the string `ALPHABET` (defined in `enigma_constants.py`), which can also serve as the index for the purposes of applying a permutation. If you implement `apply_permutation` and use it (with the permutation and offset from the fast rotor) in selecting the lamp to turn on and off in the `key_pressed` and `key_released` methods in `EnigmaMachine`, your simulation should implement this first stage. Pressing the Q key when the rotor setting is AAA should light up the lamp for the letter I. If you click on the fast rotor to advance the rotor setting to AAB, clicking Q again should light the lamp for the letter V. # Implement the Full Encryption Path (Milestone #8, EXTRA CREDIT) Once you have completed Milestone #7 (and, in particular, once you have implemented a working version of `apply_permutation`), you're ready to tackle the complete Enigma encryption path. Pressing a key on the Enigma keyboard sends a current from right to left through the fast rotor, through the middle rotor, and through the slow rotor. From there, the current enters the reflector, which implements the following fixed permutation for which the offset is always 0: ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Python REFLECTOR_PERMUTATION = "IXUHFEZDAOMTKQJWNSRLCYPBVG" ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ When the current leaves the reflector, it makes its way backward from left to right, starting with the slow rotor, moving on to the medium rotor, and finally passing through the fast rotor to arrive at one of the lamps. The complete path that arises from pressing Q is illustrated in Figure [fullstage]. As you can see from the diagram, the current flows through the fast rotor from right to left to arrive at I (index 8), through the medium rotor to arrive at X (index 23), and through the slow rotor to arrive at R (index 17). It then makes a quick loop through the reflector and emerges at S (index 18). From there, the current makes its way backward through the slow rotor straight across to S (index 18), through the medium rotor to E (index 4) and finally landing at P (index 15). ![Figure [fullstage]: Complete trace of the encryption path when the operator presses Q](lab7_images/full-stage.png) If everything is working from your previous milestones, making your way through the rotors and the reflector should not be too difficult. The challenge comes when you need to move backward through the rotors. The permutation strings show how the letters are transformed when you move through a rotor from right to left. When the signal is running from left to right, however, you can't use the permutation strings directly because the translation has to happen "backwards." What you need is the inverse of the original permutation. The idea of inverting a key is most easily illustrated by example. Suppose, that the encryption key is `"QWERTYUIOPASDFGHJKLZXCVBNM"`. That key represents the following translation table:  The translation table shows that A maps into Q, B maps into W, C maps into E, and so on. To turn the encryption process around, you have to read the translation table from bottom to top, looking to see what plaintext letter gives rise to each possible letter in the ciphertext (in cryptography terms, *plaintext* means the original document, and *ciphertext* means the encrypted version). For example, if you look for the letter A in the ciphertext, you discover that the corresponding letter in the plaintext must have been K. Similarly, the only way to get a B in the ciphertext is to start with an X in the original message. The first two entries in the inverted translation table therefore look like this:  If you continue this process by finding each letter of the alphabet on the bottom of the original translation table and then looking to see what letter appears on top, you will eventually complete the inverted table, as follows:  The inverted key is simply the 26-letter string on the bottom row, which in this case is `"KXVMCNOPHQRSZYIJADLEGWBUFT"`. To complete this milestone, you need to implement the function `invert_permutation` in `enigma_rotor.py`. In the `EnigmaRotor` constructor, you need to call `invert_permutation` so that each rotor has an instance variable for both a right-to-left and a left-to-right version of the permutation. The offset applies to each of these permutations in exactly the same way. # Implement Rotor Advance on Pressing a Key (Milestone #9, EXTRA CREDIT) The final step in the creation of the Enigma simulator is to implement the feature that advances the fast rotor every time a key is pressed. Although some sources (and most of the movies) suggest that the fast rotor advances after the key is pressed, watching the Enigma machine work makes it clear that it is the force of the key press that advances the rotor. Thus, the fast rotor advances before the translation occurs. When the fast rotor has made a complete revolution, the medium rotor advances. Similarly, when the medium rotor makes a complete revolution, the slow rotor advances. Given that you already have a method to advance a rotor and code in `EnigmaMachine` that responds to a key being pressed, the only new capability you need to implement is the "carry" from one rotor to the next. A useful technique to get this process working is to change the definition of advance so that it returns a Boolean: `False` in the usual case when no carry occurs, and `True` when the offset for that rotor wraps back to 0. The function that calls advance can check this result to determine whether it needs to propagate the carry to the next rotor. # Testing Advice - *Try to get into the spirit of the history*. Although this project is an assignment in 2020, it may help to remember that the outcome of World War II once depended on people solving precisely this problem using tools that were far more primitive that the ones you have at your disposal. Computing sometimes matters a great deal, and we may witness situations in our own lifetimes when the consequences of solving some programming challenge will be just as important. - *Draw lots of diagrams*. Understanding how the Enigma machine works is an exercise in visualization. A picture is often worth a thousand words here. - *Debug your program by seeing what values appear in the variables*. When you are debugging a program, it is far more useful to figure out what your program is doing than trying to determine why it isn’t doing what you want. Every part of this assignment works with strings, and you can get an enormous amount of information about what your program is doing by using print to display the value of the strings you’re using at interesting points. - *Check your answers against the demonstration programs*. This [demo program](TheEnigmaMachine/index.html) implements each milestone in the context of an interactive web page. Your code should generate the same results that the demo programs do. The only difference is that the demo programs don't change the font from the original image, and instead color the keys/lamps/rotors red to check that they are added correctly. # EXTRA FUN Extensions If you want to push this lab further, here are some possible extensions to consider: - Add handling for keyboard events, so that the Enigma machine responds to keyboard input - Implement other features of the Enigma machine. The German wartime Enigma was more complicated than the model presented here. In particular, the wartime machines had a stock of five rotors of which the operators could use any three in any order. The Germans also added a plugboard (Steckerbrett in German) that swapped pairs of letters before they were fed into the rotors and after they came out. - Simulate the actions of the Bombe decryption machine. This assignment has you build a simulator for the German Enigma machine. Look at the [Background Handout](cryptography-background.pdf) on Enigma decryption and consider implementing some of the British decoding strategies. # What to Turn In Submit the following files via the [Lab 7 Moodle page](https://moodle.carleton.edu/mod/assign/view.php?id=507500). - Four Python files: `enigma_machine.py`, `enigma_key.py`, `enigma_lamp.py`, and `enigma_rotor.py` - If you implemented any EXTRA FUN extensions that involved modifying `enigma_main.py`, submit that as well, along with a text file `extensions.txt` describing what you did - A plain text file called `feedback.txt` with the following information (you get points for answering these questions!): - How many hours you spent outside of class on this homework. - The difficulty of this homework for this point in a 100-level course as: too easy, easy, moderate, challenging, or too hard. - What did you learn on this homework (very briefly)? Rate the educational value relative to the time invested from 1 (low) to 5 (high). # Grading This assignment is graded out of 30 points as follows: - Submitting `feedback.txt` -- 3 points - Completing Milestone #1 -- 3 points - Completing Milestone #2 -- 3 points - Completing Milestone #3 -- 3 points - Completing Milestone #4 -- 4 points - Completing Milestone #5 -- 4.5 points - Completing Milestone #6 -- 4.5 points - Completing Milestone #7 -- 5 points **EXTRA CREDIT:** - Completing Milestone #8 -- 3 points - Completing Milestone #9 -- 2 points We will assess each Milestone by running your `enigma_main.py` and testing that the functionality specified in that Milestone is working correctly. Note that the milestones are structured to give you flexibility in terms of how much time you spend on this homework. Completing through Milestone #6 will earn 25 out of 30, and through Milestone #7 will earn full credit. Make the choice that's right for you. --- Acknowledgments: this lab adapted from [Eric Robert's Enigma Machine lab](http://people.reed.edu/~esroberts/csci121/handouts/43-Project4-Enigma.pdf). [^pgl]: PGL was created by Eric Roberts and Keith Schwarz at Stanford University (see [#RobertsSchwarz2013]). Python implementation (v0.84) and the associated documentation retrieved from Roberts' Fall 2019 offering of CSCI 121 at Reed College ([pgl.py](http://people.reed.edu/~esroberts/csci121/programs/pgl-v0.89.zip)) ([docs](http://people.reed.edu/~esroberts/csci121/pgldoc/index.html))
